Trilobe screw

Description: A trilobular thread forming screw with a machine screw’s thread pitch. As each lobe of the screw moves through the pilot hole in the nut material, it forms and work hardens the nut thread metal, producing an uninterrupted grain flow.

Industry: Electronics, Medical Device

Applications: For use in drilled, punched or cored holes in ductile metals and punch extruded metals. They provide superior prevailing torque than can be achieved with most locking screws.

Type: trilobe screw, thread forming screw

Materials: Steel 1022

Surface treatment: zinc plated, baked and waxed

Head Type: pan head

Drive Type: torx, philip

Standard: DIN 7500-1 : 2000-01 / Taptite alternative

Certificate：Material Chemical Certificate, Inspection Report
